Description
DH-PSDW81642M-A360-D440-S3
DH-PSDW81642MP-A360-D440-DC36V-S3
MSRP
> Channel 1 (Panoramic): 8 × 2 MP 1/1.8″ CMOS image sensors. Field of View:Horizontal: 1 × 360°, Vertical: 103°. Channel 2 (PTZ): 1 × 4 MP 1/1.8″ CMOS image sensors.
> Channel 2 (PTZ): 40x optical zoom, 16x digital zoom.
> Channel 2 (PTZ): Illumination distance up to 400 m.
> Channel 1 (Panoramic): Three switchable intelligent resources: Perimeter protection, Crowd map, Vehicle density.
> Channel 2 (PTZ): Three switchable intelligent resources: Perimeter protection, Video metadata, Face recognition.
> AR panorama technology; various AR tags can be overlaid.
> Smart tracking. GPS/BDS positioning.
> Smart H265+/H264+ encoding.
> WDR, 3D NR, HLC, BLC, applicable to various monitoring scenes.
>Alarm: 7 in, 3 out; audio: 2 in, 2 out; 1 channel BNC, 1 channel RS–485 (baud rate can be set). supports max. 512 G SD card.
Description
Related products
DH-IPC-HDBW5241R-ASE
- Image Sensor: 1/2.8" 2MP progressive scan STARVIS CMOS.
- Resolution: Outputs up to 2MP (1920 × 1080) at 30fps.
- Lens: 2.8mm fixed lens (other options available).
- AI Features: Includes face capture, perimeter protection, and people counting.
- IR Illumination: Built-in IR LED with a maximum range of 40m.
- Durability: IP67-rated for water and dust resistance, and IK10-rated for vandal resistance.
- Video Compression: Supports H.265 and H.264 triple-stream encoding.
DH-IPC-HDBW5442EP-ZE-2712-DC12AC24V-S3
· 1/1.8” 4Megapixel progressive scan CMOS
· H.265 & H.264 triple-stream encoding
· 25/30 fps@2688 × 1520, 50/60 fps@1080 (1920 × 1080)
· WDR (140 dB), Day/Night (ICR), 3D DNR, AWB, AGC, BLC
· Multiple network monitoring: Web viewer, CMS (DSS/PSS) & DMSS
· 2.7 mm–12.0 mm motorized lens
· 1/1 Alarm in/out, 1/1 audio in/out
· Max. IR LEDs Length 50 m
· Micro SD memory, IP67, IK10
DH-IPC-HDBW5442HP-ZHE-2712F-DC12AC24V-S3
> 4-MP 1/1.8" CMOS image sensor, low luminance, and high definition image.
> Outputs max. 4 MP (2688×1520) @25/30 fps.
> Built-in IR LED, and the max. illumination distance is 40 m.
> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.
> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
> With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc.
> Alarm: 3 in, 2 out; audio: 1 in, 1 out; RS-485; analog output; power output; supports max. 1 TB Micro SD card, built-in dual Mic.
> 24 VAC/12 VDC/PoE power supply; ePoE.
> IP67 and IK10 protection, heater.
> SMD 3.0.
>Anti-corrosion model optional.
DH-IPC-HDW5241TM-ASE
> 2-MP 1/2.8" CMOS image sensor, low luminance, and high definition image.> Outputs max. 2MP (1920×1080) @25/30fps.> Built-in IR LED, and the max. illumination distance is 50 m.> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.> With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc.> Alarm: 1 in, 1 out; audio: 1 in, 1 out; supports max. 1 TB Micro SD card, built-in MIC.> 12 VDC/PoE power supply; ePoE.> IP67 protection.>SMD 3.0.
DH-IPC-HFW5442HP-ZHE-0832-DC12AC24V-ATC-S3
> 4-MP 1/1.8" CMOS image sensor, low luminance, and high definition image.
> Outputs max. 4 MP (2688×1520) @25/30 fps.
> Built-in IR LED, and the max. illumination distance is 120 m.
> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.
> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
> With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc.
> Alarm: 3 in, 2 out; audio: 1 in, 1 out; RS-485; analog output; power output; supports max. 1 TB Micro SD card, built-in dual Mic.
> 24 VAC/12 VDC/PoE power supply; ePoE.
> IP67 and IK10 protection, heater.
> SMD 3.0.
>Anti-corrosion model optional.
DH-IPC-HFW5442HP-ZHE-2712F-DC12AC24V-S3
· 4-MP 1/1.8" CMOS image sensor, low luminance, and high definition
image.
· Outputs max. 4 MP (2688×1520) @25/30 fps.
· Built-in IR LED, and the max. illumination distance is 60 m.
· ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after
filter, flexible coding, applicable to various bandwidth and storage
environments.
· Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable
to various monitoring scenes.
· With deep learning algorithm, it supports: video metadata, smart
sound detection, IVS, face detection, smart object detection, and
people counting, etc.
· Alarm: 3 in, 2 out; audio: 1 in, 1 out; RS-485; analog output; power
output; supports max. 512 G Micro SD card, built-in dual MICs.
· 24 VAC/12 VDC/PoE power supply; ePoE.
· IP67 and IK10 protection, heater.
· SMD 3.0.
· Anti-corrosion model optional.
DH-IPC-MFW5241T2-E3-ASE
3 × 2 MP Triple-Sight Perimeter Protection Bullet WizMind Network Camera
> 3 × 2MP 1/2.8" CMOS image sensor, low luminance, and high definition image.
> Outputs max. 2 MP (1920 × 1080)@25 fps through channel1-3.
> H.265 codec, high compression rate, ultra-low bit rate.
> Built-in 8 IR LEDs, and the max. illumination distance is up to 100 m.
> Supports long-range perimeter protection. The camera can detect humans and vehicles up to 100 m away and more.
> WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
> With deep learning algorithm, it supports Perimeter Protection, including Intrusion and tripwire (the two functions support the classification and accurate detection of vehicle and human).
> Abnormality detection: Motion detection, video tampering, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.
> Alarm: 2 in, 2 out; audio: 1 in, 1 out; supports max. 1TB Micro SD card; built-in dual Mic and speaker, supports two-way talk.
> ePoE.
> IP67 and IK10 protection.
DH-IPC-MFW5241T2P-E3-ASE-0360/1200/2500B
> 3 × 2MP 1/2.8" CMOS image sensor, low luminance, and high definition image.
> Outputs max. 2 MP (1920 × 1080)@25 fps through channel1-3.
> H.265 codec, high compression rate, ultra-low bit rate.
> Built-in 8 IR LEDs, and the max. illumination distance is up to 100 m.
> Supports long-range perimeter protection. The camera can detect humans and vehicles up to 100 m away and more.
> WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
> With deep learning algorithm, it supports Perimeter Protection, including Intrusion and tripwire (the two functions support the classification and accurate detection of vehicle and human).
> Abnormality detection: Motion detection, video tampering, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.
> Alarm: 2 in, 2 out; audio: 1 in, 1 out; supports max. 1TB Micro SD card; built-in dual Mic and speaker, supports two-way talk.
> ePoE.
>IP67 and IK10 protection.
